List Price
R 1 402,91
Excluding VAT · per unit
Key Specifications
- Current Setting Range
- 20-25 A
- Short-Circuit Rating (Ics)
- 10 kA at 400 V AC
- Number of Poles
- 3
- Rated Voltage
- 690 V AC
- Trip Function
- Thermal-magnetic (overload + short-circuit)
- Standard
- IEC/EN 60947-4-1
ABB MS116 manual motor starter and circuit breaker in one compact device. Protects 3-phase motors against overload, short-circuit, and phase loss with an adjustable thermal-magnetic trip. Current range 20-25 A — set to match the motor's full-load current. Rated for direct DIN-rail or panel mounting.
Features & Benefits
- Combined motor protection and switching in one compact device
- Adjustable thermal-magnetic trip — set to motor rated current
- Phase-loss detection — protects motor from single-phasing damage
- 10 kA short-circuit rating at 400 V AC — no need for additional fuses
- Lockable in OFF position for safe LOTO motor isolation
- Accepts auxiliary contacts, under-voltage releases, and busbar connections
