List Price
R 1 238,94
Excluding VAT · per unit
Key Specifications
- Current Setting Range
- 4.00-6.30 A
- Short-Circuit Rating (Ics)
- 100 kA at 400 V AC
- Number of Poles
- 3
- Rated Voltage
- 690 V AC
- Trip Function
- Thermal-magnetic (overload + short-circuit)
- Operator Type
- Key-operated
- Standard
- IEC/EN 60947-4-1
ABB MS132 manual motor starter and circuit breaker (key-operated). Higher-performance sibling to the MS116 with 100 kA short-circuit breaking capacity throughout the full current range. Protects 3-phase motors against overload, short-circuit, and phase loss. Key-operated variant: requires key insertion to operate, preventing unauthorised switching.
Features & Benefits
- 100 kA short-circuit breaking capacity — highest Ics in the MS1xx range
- Adjustable thermal trip set to motor rated current
- Phase-loss protection — prevents single-phasing damage
- Key-operated — prevents unauthorised motor switching
- ON / OFF / TRIP position indication
- Compatible with MS1xx busbar systems, auxiliary contacts, and under-voltage releases
